Safir 9 - NEW in May 2022



The Kuzma SAFIR 9  tonearm is the best result of  our attempt to extract more music from vinyl records that has, unitil now, been heard.

The heart of the tonearm is a very rigid and stiff, sapphire conical  tube which allows the cartridge to perform to its maximum potential. The bearings are our own unique design of 4 spikes set in sapphire cups similar to those used in 4Point tonearms. All four points have minimal starting and moving friction and zero play in all directions thus ensuring that the headshell with the cartridge  moves precisely and with minimal vibration across the record.

The sapphire  tube is fitted into massive block of solid aluminium and brass, giving inert support  and further disspating vibrations which occur during playback and bearing motions.The counterweight with lock mechanism balances the tonearm. Azimuth and VTA can be adjusted in small repeatable increments with zero play, by means of an Allen key.

The tonearm is fixed on the turntable arm board via the Kuzma arm base.  VTA is adjusted by raising or lowering the tonearm’s pillar in the arm base with a VTA screw which controls its height, thus still allowing precise VTA changes when required.

Internal wiring is of superior special alloy silver wires.  A set of 4 wires runs unbroken from the cartridge pins via a 1.5 m long tonearm cable with silver RCA bullet connectors.

SAFIR 9 shows the ultimate potential of your cartridge and will reveal music hidden in the grooves, effectively, giving you a new record collection!

Release date is  mid  May 2022. Price : 20.000 EUR

Latest Reviews:

not so soon


» See all other reviews

Product photos:

VTA  adjustment screwdriver VTA  adjustment height screw- one rotation changes 0.5 mm- 0.15 deg Azimuth adjustment with zero play

Effective Length 229 mm (9 inch)
Mounting Distance From Spindle 212 mm
Offset Angle 23 deg
Tube Sapphire conical
Effective Mass 60 grams*
VTA Adjustment Yes
Azimuth Adjustment Yes
Bias Compensation/Adjustment Yes
Internal Wiring Silver Alloy
Overall Mass (Weight) 1250 grams
Projected List Price EUR 20.000 EUR
*Suitable for cartridges with CU below 25- tonearm resonanes will be in range of 5-7 Hz which is preferable

Manual- soon
